Finite Optical System Biological Microscope With Coaxial Coarse / Fine Focusing , A12.1035

Finite Optical System Biological Microscope With Coaxial Coarse / Fine Focusing , A12.1035
Finite Optical System Biological Microscope With Coaxial Coarse / Fine Focusing , A12.1035 Finite Optical System Biological Microscope With Coaxial Coarse / Fine Focusing , A12.1035

Large Image :  Finite Optical System Biological Microscope With Coaxial Coarse / Fine Focusing , A12.1035

Product Details:
Place of Origin: China
Brand Name: CNOEC
Certification: CE
Model Number: A12.1035
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Carton
Delivery Time: 1month
Payment Terms: T/T,West Union and Paypal
Supply Ability: 10000
Detailed Product Description
Product Name: Biological Microscope Optical System: Finite Optical System
Stage: Double Layers Mechanical Stage Focusing: Coaxial Coarse And Fine Adjustment
Condenser: Abbe Condenser N.A.1.25 Illumination: S-LED Illumination
High Light:

high powered microscope

,

biological compound microscope



Finite Optical System Biological Microscope With Coaxial Coarse and Fine Focusing A12.1035





Specification

A12.1035 Biological Microscope
B
T
BE
TE
Optical System Finite Optical System
Eyepiece WF10X/18
Viewing Head Monocular Head Inclined at 30°
Seidentopf Binocular Viewing Head Inclined at 30°, Interpupillary 47-78mm


Seidentopf Trinocular Viewing Head Inclined at 30°, Interpupillary 47-78mm


Digital Viewing Head Inclined at 30°, Interpupillary 47-78mm, 5M pixels, Support Wifi
Digital Viewing Head Inclined at 30°, Interpupillary 47-78mm, 5M pixels, 8" LCD. Android OS
Achromatic Objective 4X N.A=0.1 WD=37.5
10X N.A=0.25 WD=7.316
20X N.A=0.4 WD=13
40X N.A=0.65 WD=0.632
100X N.A=1.25 WD=0.198
Nosepiece Backward Quadruple Nosepiece
Stage Double Layers Mechanical Stage 140X140mm, Moving Range 75X50mm
Condenser NA1.25 Abbe Condenser
Dark Field Condenser (Dry, Oil)
Focusing System Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Moving Range 25mm
Illumination Halogen Lamp 6V/20W
S-LED Illumination
S-LED Illumination with Recharger
Kohler Illumination
ECO Function (Auto Power Off After 30 Mins No Operation)
Plane-concave Mirror
Fluorescent Attachment Fluorescent Illumination, LED Lamp
Fluorescent Illumination, 100W HBOLamp
Polarzation Set
Phase Contrast Kit

Note: ● Standar Outfit , ○ Optional
